DATEQ MA-60D 60W PA Mixing Amplifier with Media Player, BT and DAB+

DATEQ MA-60D 60W PA Mixing Amplifier with Media Player, BT and DAB+

RRP

£275.00

inc VAT

£275.00
Sold out
Tax included. Shipping calculated at checkout.
DATEQ MA-60D 100V/Low-Z Mixing Amplifier   The DATEQ MA-60D is a versatile tabletop mixing amplifier designed for commercial background music and public address (PA) systems. It features a compact design,...
Vendor: DATEQ
SKU: MA-60D

Product Specification

Access Manufacturer's website for detailed product specifications and documents.

Want to see trade pricing? Register for a trade account!

You can apply for a trade account with us by either;

1. Registering at our B2B Trade Portal - Our dedicated online trade portal gives you a seamless buying experience. See trade pricing, view stock availability, place orders and check your order status.

2. Completing a trade application form and returning via email to sales@epicaudio.co.uk.

Project Enquiry

We specialise in commercial projects offering a comprehensive commercial project service, collaborating with you to design, supply, and install solutions that meet your specifications, timeline, and budget.

Get in touch today to discuss your requirements!

View full product details

DATEQ MA-60D 100V/Low-Z Mixing Amplifier



The DATEQ MA-60D is a versatile tabletop mixing amplifier designed for commercial background music and public address (PA) systems. It features a compact design, integrated media sources, and flexible output options for both high-voltage (100V/70V) and low-impedance speakers.



Key Features and Functionality



  • Product Type: Tabletop Mixing Amplifier with Media Player.

  • Rated Power Output: 60 W RMS (Root Mean Square).

  • Speaker Output: Highly versatile, supporting:

    • 100 V line

    • 70 V line

    • 4-16 Ω low-impedance speakers

  • Integrated Media Player: Built-in audio source capabilities include:

    • MP3/USB/SD (media playback)

    • FM/DAB+ (Digital Audio Broadcasting plus FM radio)

    • Bluetooth connectivity

  • Mixing Inputs: Comprehensive input panel for various sources:

    • 3 x Mic/Line inputs

    • 2 x RCA Line inputs

    • 1 x TEL input (for priority telephone/emergency announcements)

    • 1 x XLR input with switchable +48V phantom power (for condenser microphones)

  • Protection and Power: Equipped with protection against short-circuit, clip, overload, and high temperature. Operates on standard 230V AC or 24V DC power supply.



Technical Specifications Summary

Feature Detail
Product Type Mixing Amplifier with Integrated Media Player
RMS Power 60 W
Speaker Output 100 V, 70 V, 4-16 Ω
Media Sources USB/SD (MP3), FM/DAB+, Bluetooth
Microphone Inputs 3 x Mic/Line, 1 x XLR (+48V Phantom Power)
Power Options 230V AC or 24V DC
Form Factor Tabletop
