The Fonestar MAX-240Z is an integrated Public Address (PA) multi-zone amplifier designed for background music and public announcement systems in environments like commercial premises, educational centers, bars, and restaurants. It features a modern, high-efficiency Class D amplifier and is built for reliable, long-term operation.
Output Power: 240 W RMS.
Multi-Zone Control: 4 speaker output zones with individual 7-position volume control and an Off switch.
Integrated Player: Features a built-in Bluetooth 5.3/USB/FM player for ambient music.
Priority and Security: Includes Emergency input and mute for connection to alarm systems, and outputs for 24 V Attenuator Priority and a 3rd Priority Wire for managing audio levels during emergency announcements.
Speaker Outputs: Supports 100 V, 70 V, and 4 Ω speaker lines.
Microphone Inputs: 4 balanced micro/line inputs (CH 1, 2, 3, 4) with selectable Phantom 48V, ringtone generator (Chime), and various priority levels. Dedicated inputs for the ZONEMIC-6 zone microphone and a remote wall panel.
Design: Can be used as a desktop unit or mounted in a 2 U 19” rack (rack mounts included). It features silent, maintenance-free induction cooling (fanless).
| Feature | Specification |
| Power | 240 W RMS |
| Response | 45 - 22,000 Hz (-10 dB) |
| Distortion | THD+N: <0.5% at 1 kHz |
| Speaker Outputs | 100 V, 70 V, or 4 Ω; 4 x 100 V speaker zones with 7-position volume selector and OFF |
| Player | Bluetooth 5.3 / USB / FM |
| Inputs | ZONEMIC-6 (RJ45), Remote wall panel (RJ45), 4 x Combo/Euroblock (Mic/Line/Phantom), 3 x AUX (RCA), 1 x Emergency (Euroblock), Mute (contact closure) |
| Impedance | 4 Ω, 100 V (42 Ω), and 70 V (20 Ω) line |
| Power Consumption | 345 W |
| Dimensions (W x H x D) | 430 x 89 x 320 mm (2 U 19” rack) |
| Weight | 8.8 kg |
