* Great power and sound quality in just 1 U rack
* 2 x audio channels
* High efficiency high reliability class D amplifier
* Secure, easy-to-connect euroblock connectors
* DANTE mod. compatible. FSD-22D
Multi-channel PA power amplifier with 100 V line output.
Powerful power amplifier in only 1 U 19" rack.
Suitable for PA installations with 100 V or 70 V loudspeakers.
Class D amplifier with high efficiency and high reliability due to low-maintenance protection circuits.
Secure, easy-to-connect euroblock connectors.
DANTE support via optional FSD-22D model.
Great sound quality and low noise.
Reduced weight.
For multi-zone PA and piped music systems with 100 V or 70 V line loudspeakers. Commercial premises, sports centres, educational establishments, conference rooms, cafés, restaurants, theme parks, etc.
FEATURES:
2-channel PA power amplifier.
100 V or 70 V output for PA installations.
Highly efficient and reliable class D amplifier thanks to low-maintenance protection circuits
Safe and easily connectable euroblock connectors.
Excellent sound quality and little noise.
POWER:
2 x 400 W RMS or 1 x 480 W RMS (single channel)
GAIN:
40 dB
RESPONSE:
60-20.000 Hz (-10 dB)
DISTORSION:
THD+N: <0.1% (1 kHz, 1/8 rated power, A-weighted)
DYNAMIC RANGE:
>95 dBA (rated power)
CROSSTALK:
>70 dB (rated power)
DAMPING FACTOR:
>200 (1 kHz, 8 Ω)
INPUTS:
2 balanced/unbalanced auxiliary lines, euroblock, 20.000 Ω/10.000 Ω, 1 V RMS (0 dBV)
1 emergency/test, euroblock, 1 V RMS (0 dBV)
OUTPUTS:
1 GPIO fault indicator output, 5 V DC, euroblock
FUNCTIONS:
Forced ventilation with variable speed according to the temperature
LED power, protection, priority and peak signal indicators
Emergency input priority/contact closure test, euroblock
Disabling/mute via contact closure, euroblock
PROTECTION:
Short circuit, open circuit, temperature, ultrasound and radio frequency
CONTROLS:
Volume for each channel
100/70 V switch on rear panel
IMPEDANCE:
100 and 70 V, euroblock
TEMPERATURE RANGE:
Operation: 0ºC ~ 50ºC
POWER SUPPLY:
230 V AC, 1,200 W maximum
115 V AC on demand
DIMENSIONS:
483 x 44 x 380 mm depth. 1 U 19" rack
WEIGHT:
5.15 kg
OPTIONAL:
FSD-22D: DANTE expansion module
ACCESSORIES:
Anti-slip adhesive pads
